Guest post by - Rakesh Rao, DesignSense Bricscad V15 Manual PdfĪFAIK the new BricsBIM v15 is unique amongst the Building Modelers - Revit, Archicad etc and the one I've paid for, Bentley Building Designer. In general, using Materials is a lot more easier now.
Using real-world materials in rendering has gotten significantly easier.DMEXTRUDEMODE: system variable which determines whether DMEXTRUDE and DMREVOLVE commands create new solids or do boolean union when their ‘Auto’ option is used.DELETETOOL: system variable to control whether ‘tool’ entities ( subtracted entities ) used during the SUBTRACT command are deleted or retained.ANTIALIASRENDER and ANTIALIASSCREEN system variables control the amount of anti-aliasing during rendering.V15 extends this further by adding a number of additional variables. One of the hidden gems in BricsCAD is the ability to have fine tuned control of the program using a whole lot of BricsCAD-only system variables.
#BRICSCAD V16.2.15 1 MAC#
Click for larger imageRR comments: Previously this feature was only available on Linux and Mac versions, now a Windows implementation based on Daniel Marcotte’s DocTabs utility has been added.The ShowDocTabs setting controls whether a tab is displayed for each opened document. Multiple drawings can now be displayed in tabs. This allows you to make one copy of selcted entities and repeat the copy operation in the same direction automatically. A REPEAT option has been added to the COPY command.Good to see it as a native command in BricsCAD. Going by the huge number of Lisp routines offering visibility control to CAD entities, this was long overdue. RR comments: We had this in CADPower since a while. UNISOLATEOBJECTS/UNISOLATE/UNHIDE: unhides objects that were hidden.ISOLATEOBJECTS/ISOLATE: hides all but the selected objects.HIDEOBJECTS: hides the selected objects.New commands: HIDEOBJECTS, ISOLATEOBJECTS andUNISOLATEOBJECTS.It has been requested by a number of users. Dynamic blocks now can be edited in-place using following grip types:.The assistant widget appears to make sure this interesting feature does not go unnoticed. Controllede using the new ‘Tip’ field in status bar.Ctrl key. HOT KEY TIP: a QUAD-like assistant widget provides options controlled by Ctrl Key.Parameters defined in a component file can be changed in a higher level assembly maintaining the link to the source component definition. ASSEMBLY DESIGN: introduced parametric components.Earlier, this was possible only at the part level. A new command calledBMMASSPROP now generates mass properties for the entire assembly. Material Density property for components: It is now possible to assign a material denisty to the entire component.Workspaces: now allow you to setup your UI compnents for 2d, 3d, Mechanical & look-and-feel.Configurable for 3rd party applications!! Click here to see how V15 ribbons look like. BricsCAD now sports a ribbon user-interface also.Hans de Backer, Head of Product Development at Bricsys kicks off Day 2 of the conference with a presentation of all that is new in BricsCAD.īricsCAD V15 is packed with a lots of new features and fine tweaks that improve usability, enhance productivity. 0 comments,, by Guest/blogger, in BricsCAD,BricsCAD,Exclusive Articles
